A plastic/polymer implant ready for inspection on the VisionGauge Digital Optical Comparator
Media Category: Applications
Images related to applications solved with the VisionGauge Digital Optical Comparator
medical plastic implant measurements
VisionGauge OnLine performing radius/diameter measurements on medical plastic/polymer implants.
medical industry plastic implant measurements
VisionGauge OnLine performs multiple manual and automated measurements on plastic/polymer medical implants
hip stem replacement – radiograph
Many total hip replacement implants contain ultra-high molecular-weight polyethylene (UHMWPE).
out of tolerance area – sketch2
VisionGauge OnLine’s new CAD Fitting tool only affects currently out of tolerance areas (highlighted in red)
Out of tolerance edge – sketch1
Sketch 1 shows an area of a part that is out of tolerance. The CAD Auto-Align™ tool would attempt to carry out the correction “A” to align the CAD nominal and the part. The CAD Fitting™ tool, on the other hand, would only attempt to bring the part back in the tolerance band, i.e. applying the smaller correction “B”.
Medical part CAD Fitting results
The results of VisionGauge OnLine’s CAD Fitting on a medical part.
medical part CAD Auto-Align result
The results of VisionGauge OnLine’s CAD Auto-Align on a medical part
Aerospace part CAD Fitting results
The results of VisionGauge OnLine’s new CAD Fitting on an aerospace part.
Aerospace part CAD Auto-Align results vs CAD Fitting
The results of the VisionGauge OnLine’s CAD Auto-Align tool applied on an aerospace part
